Output voltage: 7.8 mV per channel at 1 kHz.; 5 cm./sec. peak recorded velocity.
-
Channel balance: 2.0 dB at 1 kHz.
-
Channel separation: 20 dB at 1 kHz.
-
Frequency response: 20-20 kHz ą 2 dB.
-
Tracking ability: 80 ľm at 315Hz at recommended tracking force.
-
Stylus type: Elliptical.
-
Stylus tip radius: 0.4 mil. x 0.7 mil. Elliptical.
-
Tracking force range: 2.0-4.0 grams.
-
Recommended tracking force: 3.0 grams.
-
Tracking angle: 20°.
-
Optimum load: 47, 000 ohms resistance in parallel with 275 to picofarads total capacitance.
-
Cartridge weight: 5.75 g.
-
Mounting: Standard 1/2" (12.7mm) Mounting Centers.
-
Replacement stylus: RSQ32.
